Flat Ribbon Cable 0.1" FRC Connector Breakout Board Module (IDC10 2x5Pin)

KWD 5.500
Weight
23 g
StyleIDC10 2x5Pin
– 1 +

Special Features

  • IDC Male header connector, pin pitch 0.1" / 2.54mm.
  • Terminal block: Wire range - 26-16AWG. Strip length - 5mm. Screws - M2,steel,Cr3+ Zn plated. Torque - 0.2Nm (1.7Lb-In.). Pin header and Cage - Brass.
  • Rated voltage: 60V. Rated current: 1A / per pin. Operating temperature: -20 to 50 Celsius.
  • FR-4 fiber glass PCB, dual copper layers.
  • Datasheet: https://images-na.ssl-images-amazon.com/images/I/A1UVn9hNcBL.pdf

Description

IDC Male header connector, pin pitch 0.1" / 2.54mm.
Terminal block: Wire range - 26-16AWG. Strip length - 5mm. Screws - M2,steel,Cr3+ Zn plated. Torque - 0.2Nm (1.7Lb-In.). Pin header and Cage - Brass.
Rated voltage: 60V. Rated current: 1A / per pin.
Operating temperature: -20 to 50 Celsius.
FR-4 fiber glass PCB, dual copper layers.
Datasheet: https://images-na.ssl-images-amazon.com/images/I/A1UVn9hNcBL.pdf
