Feature:
1. GOOD AIRTIGHTNESS: Come with transparent container cup, possess high temperature resistance, high strength, and good airtightness
2. ACCURATE READING: Accurate pressure gauge provide accurate reading, easy to observe, very convenient to use
3. ADJUST PRESSURE STRENGTH INDEPENDENTLY: Pull up the pressure regulating valve to unlock, and adjust the pressure strength independently
4. GOOD QUALITY ALUMINUM ALLOY Made of good quality aluminum alloy material, not easy to corrode and rust, possess high accuracy and long service life
5. FOR PNEUMATIC SYSTEMS: Used for filtration, oil water separation in water treatment, pneumatic systems, and automation equipment

Specification:
Item Type: Compressed Filter Regulator Combo
Material: Aluminum alloy
Guaranteed Pressure Resistance: 1.5MPa (15kgf/cm²)
Maximum Working Pressure: 1.0MPa (10kgf/cm²)
Environment and Fluid Temperature: 5-60℃
Filter Element Accuracy: 40μm
Protective Cover: Included
Model SFR200 SFR300 SFR400 Connecting pipe caliber G1/4 G3/8 G1/2 Pressure gauge caliber G1/8 G1/8 G1/8

Package List:
1 x Filter
1 x Pressure Gauge
1 x Bracket Board

Note:
1. Keep the pipeline clean and prolong the service life.
2. The bowl body is made of polycarbonate resin. Do not use solvents such as trichloroethylene diluent. Use dish for cleaning.
