L293D stepper motor drive have 16-pin design and channel channel capability up to 600mAh output current.it's mainly made of durable hard alloy and plastic materials,h over-temperature protection and easy to use

Specification:

Remember No.: 16 pins
- Channel Capability: 600mA output current / channel
Absolute Maximum Ratings:
- Vs Operating voltage: 36 V
- Vss Logic Supply Voltage: 36V
- Vi input signals: 7 V
- Ven activate: 7 V
- Io peak output current (100 us not repetitive): 1.2A
- PEL Total power dissipation at T-pins: 90 Celsius, 4W
-Tstg, Tj storage and Junction temperature: -40 Celsius to 150 Celsius
- Logical /0/ input voltage up to 1.5V (High noise immunity).
- Internal clamp diodes.
Weight:50g

Package content:6Pcs L293D DIP 16-pin IC Stepper Motor Drive Controller
