Pneumatic Cylinder, SMC Type 15mm 180 Degree Rotary Pneumatic Air Cylinder, M5*0.8 Import Size, 0.1-1.0MPa

Features:
1. Made of high quality aluminum alloy cylinder, sturdy, anti-corrosion and not easy to rust.
2. With the increase of pressure, it automatically improves the sealing performance and lasts for a long time
3. Built-in magnetic ring for magnetic switch
4. With angle adjustment unit, you can adjust the angle at 0-180°
5. The surface of the cylinder has increased the hard oxidation technology, which increases the surface hardness of the cylinder, is not easy to deform, and is durable.
6. Flexible bearing rotation and precise positioning

Specification:
Condition: 100% Brand New
Model: MSQB-10A
Fluid: Air(no oil)
Max Using Pressure: 1Mpa with Screw
Min Using Pressure: 0.1Mpa
Environment Temperature and Fluid Temperature: 0~60°C
Angle Adjustment Range: 0-180°
Max Swing Angle: 180°
Cylinder Inner Diameter: 15mm
Import Size: M5*0.8
Weight: Approx. 530g / 18.7oz

Package List:
1 * MSQB-10A Pneumatic Cylinder
