20PCS DB9 Male and Female Solder Type Connector, RS232 Serial 9 Pin D Sub Adapter for PC Accessories(Male x 10, Female x 10)

Special Features

Durable: Solder cup connectors more firm and stable, not easy to break when under tension.
Stability: RS232 serial D-Sub 25 pin connectors. Nickel plated housing with pure copper joints, resistance to plug and stable transmission.
Flexibility: Compact and light weight allows you to make up your own custom cables with DB25 connectors. Solder Cup connectors can be soldered to cable ends or mounted directly to a PCB card edge.
Widely Application: These DB-25 connectors are useful for a wide variety of electronics projects; common applications include I/O and DAQ equipment, computer parallel ports, and serial ports.
Maximum wire size is 20 AWG

Description

Solder type connection between the cable and connector is very easy to connect and creates permanent and extremely durable connections from cable to connector.
Specifications：
Insulator:PBT
Contact Material: Copper
Shell: Nickel plated
Type: Welding type
Pin: 25 pin
Rated Voltage:24V
Rated Current:2A
Contact Resistance: 30mΩ
Insulation Resistance:100MΩ; Min. AT 500V DC
Withstand Voltage:1000V AC for 1 minute Min.
Operating temperature:-67℉~221℉/-55℃~105℃
Package Included：
10 X Male DB25 Solder Type Connectors
10 X Female DB25 Solder Type Connectors
