ER11 Collet Chuck CNC Spindle, ER-11 Collet Lathe Tool Holder, Router Collet Extension for Boring, Milling, Drilling, Tapping, Grinding and Other Processing

KWD 5
Weight
51 g
All electronics ship with US style plugs. You may need a voltage converter or a plug adapter.
– 1 +

Special Features

  • [High-quality Steel]: This er11 collet set is made of high-quality steel, which has good strength and good durability
  • [Precision Grinding]: This er11 collet chuck cnc spindle is precision ground to eliminate imbalance and increase safety during cutting
  • [Good Substitute]: This er-11 collet lathe tool holder can reduce costs, improve efficiency, which can replace your old collet well
  • [Size]: The shaft hole of this router collet extension is 8mm (+0.02 mm) and needs to be heated and expanded, the shaft diameter is 18mm, the nut diameter is 13mm, and the nut diameter is 18mm.
  • [Wide Application]: This er11 spring collet is widely used in boring, milling, drilling, tapping, grinding and other processing

Description

Features:
- This motor shaft collet is made of high quality steel material, straight shank with clamping nut to be tightened.
- Extension rod diameter and the other parts are precision ground to eliminate unbalance, increase safety when cutting.
- Straight extended shank fits for deep processing, meeting the needs of extending the depth of processing.
- Collet is well packed in a protective container with label for safe transportation and storage.
- It is widely used in boring, milling, drilling, tapping, grinding and other processing.

Specifications:
Type: ER11A-8mm
Material: Steel
Height: 40mm / 1.57"
Shaft Diameter: 16mm / 0.63"
Shaft Inner Diameter: 8mm(±0.02mm) / 0.31"
Nut Diameter: 19mm / 7.48"
Nut Inner Diameter: 9mm / 3.54"

Package Includes:
1 x Collet

Note:
Please allow 1-2mm error due to manual measurement. Thanks for your understanding.
