5V solid state relays per channel 250V 2A, output with resistive fuse 250V 2A
Features:
8 channel 2 AMP Solid State Relay board Good for lighting- holiday displays etc
The input control signal voltage: (0-0.5V LOW solid state relay OFF) (2.5-20V high solid state relays ON)
Rated output load: 2A at 100 to 240VAC (50/60Hz)
Load voltage range: 75 to 264VAC (50/60Hz)
Load current: 0. 1 to 2 AMP
Power supply: 5VDC / 160mA (all channel ON)
Load type: General purpose
Isolation: Phototriac
Zero cross: Yes
Module interface:
Input section:
DC+: positive power supply (by relay voltage power supply)
DC-: connect power negative
CH1: 1 relay module signal to trigger the end (high level trigger effective)
CH2: 2-channel relay module signal to trigger the end (high level trigger effective)
CH3: 3 relay module signal to trigger the end (high level trigger effective)
CH4: 4-channel relay module signal to trigger the end (high level trigger effective)
CH5: 5 relay module signal to trigger the end (high level trigger effective)
CH6: 6-channel relay module signal to trigger the end (high level trigger effective)
CH7: 7 relay module signal to trigger the end (high level trigger effective)
CH8: 8-channel relay module signal to trigger the end (high level trigger effective)
Package list:
1 x AiTrip 8 Channel 5V solid state relay module board
