Pin description
1. VDD Power Supply 3.3-5.5V DC
2. GND grounding, power supply negative pole
3. SDA Serial Data, Two-way Port
4. SCL Serial Clock, Input Port
Technical parameters:
1. Measurement range of humidity:0~100%RH
2. Precision of humidity measurement: ±2%RH
3. Temperature Measurement Range: -40~125°
4. Accuracy of temperature measurement: ±0.2°
5. Working Voltage: 3.3~5VDC
6. I2C Interface Output
Applications:
HVAC, dehumidifier, agriculture, cold chain storage, testing and testing equipment, consumer goods, automobiles, automatic control, data recorder, weather station, household appliances, humidity regulator, medical treatment, and other related humidity detection and control.
