Specification:
Item Type: Robot Servo
Material: Alloy Steel
Model: ASMG-MTB
Rated Voltage: 12V/24V (11V/MIN~30V/Maximum, Limit Voltage
No Load Current: Limit Angle: ±180° or 0°-360°(Maximum) The steering gear has electronic limit adjustment
RC Mode: 1ms Pulse Mode: 1ms-2ms (Pulse Width)/50Hz (Cranial Rate) suitable for wireless remote Way control
2ms Pulse Mode: 0.5ms~2.5ms (pulse width)/50Hz (frequency), suitable for multiple rudder control Machine controller mode control
Analog Voltage Mode: 0V-3.3V Input Voltage (OV Corresponds to 0, 3.3V Corresponds to 360°)
Control Resolution: 360°Corresponding to 15 Bit Resolution (32768), ARM 32 Bit MCU, Real Gigital Port to Read Magnetic Encoding Data
Mechanical Life: >1,000,000 Times Full Load (Conservative Value)
Limit Parameters:
Limit Voltage: 11V-30V/DC (Maximum)
Current Limit Value: 10A±0.2A(Maximum)
Working Angle: ±180° or 0°~360°(Maximum)
RC Mode
1ms Pulse Mode: 1ms-2ms (Pulse Width) 50Hz-333Hz (Frequency)
2ms Pulse Mode: 0.5ms-2.5ms (Pulse Width)/50Hz-333Hz (Frequency)
Analog Voltage Mode: 0V-3.3V Input Voltage 0V Corresponds to 0°, 3.3V Corresponds to 360

Package List:
1 x Steering Motor

Note:
Don't overload use
