Features:
★ 4 Pole 12 Slot Hi-torque Motor Design
★ CNC Machined 6061 T6 Billet Aluminum Heatsink Can
★ High Purity Copper Windings Maximizes Efficiency
★ High RPM ABEC5 Oversized Bearings
★ Precision balanced rotor,smoothness for best reliability and maximum RPM
★ Stator - Super Thin (0.2mm) Laminations
★ Removable/Replaceable Rotor
★ Precision Engineered for Maximum Energy Conversion
★ Suitable for RC Boat
Specification:
Brand: KingVal
Product: 2948 Boat Brushless Motor
KV(RPM/Volt): 6800KV
Max Amps: 116A
Max Voltage:
Max Power: 1000W
Motor Size: ø29x48mm
Winding Type: DELTA
Number of Turns: 2.5T
No Load Current: 4.0A
Max RPM: 60K
Shaft Diameter: 3.175mm
Rotor Poles: 4
Weight: 118g
Water Cooling Jacket:
Dimension: ø37x39mm
Weight: 24g
Package List:
1 x 2948 Brushless Motor
1 x Water Cooling Jacket
