PERFORMANCE
Processor: Intel Core i7-12800HX, 16C (8P + 8E) / 24T, P-core 2 / 4.8GHz, E-core 1.5 / 3.4GHz, 25MB
Graphics: NVIDIA RTX A1000 4GB GDDR6
Chipset: Intel WM690
Memory: 2x 32GB SO-DIMM DDR5-4800 non-ECC
Memory Slots: Four DDR5 SO-DIMM slots, dual-channel capable
Max Memory: Up to 128GB
Storage: 1TB SSD M.2 2280 PCIe Gen 4x4 Performance NVMe Opal2
Storage Support: Up to two drives, 2x M.2 SSD M.2 2280 SSD up to 8TB, 4TB each RAID 0/1 support
Storage Slot: Two M.2 slots Two M.2 2280 PCIe Gen 4x4 slots, support M.2 2280 SSD
RAID PresetNone
Card Reader: SD 7.0 Card Reader
Optical: None
Audio Chip: High Definition (HD) Audio, Realtek ALC3306 codec
Speakers: Stereo speakers, 2W x2, Dolby Atmos
Camera: IR & FHD 1080p with Privacy Shutter
Microphone: 2x, Array
Battery: Integrated 94Wh
Power Adapter: 170W Slim Tip (3-pin)
DESIGN
Display: 16.0" WQUXGA (3840x2400) IPS 600nits Anti-glare, 16:10, 100% Adobe RGB, Low Blue Light, Dolby Vision, HDR 400, X-Rite Pantone Factory Color Calibration, DC Dimming
Touchscreen: None
Color Calibrator: Factory Color Calibration
Keyboard: Backlit, English
Case Color: Storm Grey
Dimensions: (WxDxH)364 x 266 x 30.23 mm (14.3 x 10.5 x 1.2 inches)
Weight: Starting at 2.95 kg (6.5 lbs)
SOFTWARE
Operating System: Windows 11 Pro 64, English
Bundled Software: None
CONNECTIVITY
Ethernet: None
WLAN + Bluetooth: Intel AX211 Wi-Fi 6E, 2x2 + BT5.2
WWAN: None
SIM Card: None
Standard Ports: Models with NVIDIA graphics: 1x HDMI, up to 8K/60Hz2x USB 3.2 Gen 1 (one Always On)1x USB-C 3.2 Gen 2 (support data transfer, Power Delivery 3.0, and DisplayPort 1.4)2x Thunderbolt 4 / USB4 40Gbps (support data transfer, Power Delivery 3.0 and DisplayPort 1.4)1x SD Express 7.0 card reader
Optional Ports (configured)1x Nano-SIM card slot (WWAN support models)
Docking: Various docking solutions are supported via Thunderbolt or USB-C. For more compatible docking solutions, please visit Docking for ThinkPad P16 Gen 1
Monitor Cable: None
