Terminal Fuse 150A Marine Rated Battery Fuse (MRBF) 58V DC Max IP66 Waterproof

Application:

🔍Full range circuit protection for automotive and marine applications.
The breaking capacity meets the requirements of conventional vehicle batteries and 12V, 24V and 42V electrical networks.
10,000 AIC at 14V DC satisfies ABYC requirements for DC Main circuit protection on large battery banks.

🔍Compact, high-amp fuse appropriate for DC Main, inverters, windlass and bow thruster circuit protection.
Designed to provide high current protection in tight space constraints.
Ignition protected when used with MRBF Terminal Fuse Blocks.
Isolated stud design uses standard M8 hardware and permits stacking of terminals.

🔍Suitable for main and auxiliary circuit protection such as alternator outputs, starter motor inputs and accessory circuits.
Alleviates having to make up a short wire to connect to a standard fuse block to the battery.

Specification:
Rated Current: 150A
Rated Voltage: 58VDC
Ingress Protection: IP66
Ignition Protected: Per SAEJ1117
Interrupt Capacity: 10000A @ 14VDC, 5000A @ 32VDC, 2000A @ 58VDC
Maximum Torque: 12Nm (1224Kgf-cm) (106 in-lbs)
Material: body, insulating material ceramic; housing & cover, UL-rated 94V0 thermoplastic; fuse, copper alloy (nickel plated), ring terminals, tin plated
Features: high load capacity, ignition protection, visible fuse, security, easy to install
Notice: DO NOT mount fuse directly onto battery post. Fuses should be mounted on the MRBF terminal fuse block.

Package Included:
1 X MRBF Battery Terminal Fuse 150A
