Compatible P/N:
LM723 723CN LM723C LM723CN UA723PC MC1723CP
Description:
Condition: 100% Brand New And High Quality
Material: Electrical Components
Color: See Pictures
Encapsulation: DIP-14
Input voltage up to 40V
Output voltage adjustable from 2 to 37V
Positive or negative supply operation
Series, shunt. switching or floating operation
Output current to 150 mA without external pass transistor
Adjustable current limiting
Operating Temperature: 0 °C~+70 °C
Size: 19mm x 8.6mm x 7.2mm
Quantity: 15 Pcs
The LM723 is a monolithic integrated programmable voltage regulator, the circuit provides internal current limiting. When the output current exceeds 150 mA an external NPN or PNP pass element may be used. Provisions are made for adjustable current limiting and remote shutdown.
