Compatible P/N:
3900N LM3900 LM3900N LM3900NE4 NJM3900N JRC3900N
Description:
Condition: 100% Brand New And High Quality
Material: Electrical Components
Color: See Pictures
Encapsulation: DIP-14
Manufacturer Type: General Purpose Amplifier
Number of Channels per Chip: 4
Process Technology: Bipolar
Minimum Single Supply Voltage (V): 4.5
Typical Single Supply Voltage (V): 28/18/15/12/24/9/5
Maximum Single Supply Voltage (V): 32
Minimum Dual Supply Voltage (V): ±2.2
Typical Dual Supply Voltage (V): ±15/±12/±9/±5/±3
Maximum Dual Supply Voltage (V): ±16
Maximum Input Bias Current (uA): 0.2@15V
Maximum Quiescent Current (mA): 10@15V
Power Supply Type: Single|Dual
Maximum Power Dissipation (mW): 1150
Typical Slew Rate (V/us): 20@±15V
Typical Voltage Gain (dB): 68.94
Typical Gain Bandwidth Product (MHz): 2.5
Operating Temperature: 0 °C~+70 °C
Size: 19mm x 8.6mm x 7.2mm
Quantity: 5 Pcs
NOTE: Kindly compare your original item with the photos provided for the listing to make sure that you are purchasing the correct part. we don't provide technical assistance please make sure you are familiar with the product before purchasing. apologize in advance.
