Description:
Feature:
Good shrinking and sealing and excellent wetting of the wires.
You can pull hard and it won't separate unless you don't let it cool before tugging on it.
Perfect for DIY projects for your car, bike, and some home applications ect.Easy to use.
Using Steps:
1.Peel the wire jacket off.
2.Insert the wire into the connector.
3.Tighten the wires and move them to the center of the tube.
4.Heat the shrinkable tube by lighter or a heat gun.Start by waving the flame back and forth at the middle section until the solder melts. Then, let cool for about 10 seconds.
5.Once the center area is soldered and cooled you can proceed to seal the 2 sides. If you dont wait for the solder to cool in the middle, it will remain pliable, soft, and you'll have to contend with the wire shifting around while you work on sealing the edges.
Specification:
Insulation: PE
Plating: tin
Terminal Body: copper
Working temperature:-55℃-125℃
Start shrinking temperature:80℃
Tin start melting temperature:138℃
Tin complete melting temperature:160℃
Shrink temperature>160℃
Protection class:IP 67
Size: Orange:AWG 8,Cable cross-section 10mm2; length:30mm/1.18 inch,interface diameter:7.3mm
Package list:60pcs heat shrink connectors
