These base connection fittings are suitable for SC63 series air cylinders, making them versatile for applications requiring this specific cylinder size. Whether used in industrial automation, machinery, or other pneumatic systems, these fittings will enhance the functionality and efficiency of your setup.

Specification
Material: Iron
Mounting Hole Diameter: 38.3mm/ 1.51 inch
Small Hole Diameter: 9mm/ 0.35 inch
Small Hole Distance: 56mm/ 2.2 inch
Overall Size: 116mm x 75mm x 12mm/ 4.57 inch x 2.95 inch x 0.47 inch (L*W*H)
Package Contents: 1 x Air Cylinder Base

Advantage
The Air Cylinder Base Connection Fittings are specifically designed for Bore 63mm air cylinders and serve as standard type pneumatic parts. With its precise design and construction, these fittings provide reliable performance and ease of installation. This ensures a secure and stable mounting of the air cylinder.

Instruction
To install, simply follow the manufacturer's instructions and attach the base connection fittings to the corresponding ports of your SC63 air cylinder. Ensure a secure connection for optimal performance.

Note
It is important to regularly inspect the base connection fittings and flange mounting plate for any signs of wear or damage. Replace them if necessary to maintain optimal performance and safety of the air cylinder.
