How to Use:
1. Power on
Press the POWER button to turn on the power, and the screen will display the voltage and current values that were set when the machine was turned off last time.
2. Voltage setting
Regardless of whether the power supply is in the output state, you can turn the "VOLTAGE" coding switch to set the voltage. When entering the voltage setting state, the currently set "bit" will flash in a flashing manner; turn clockwise to increase the value, and turn counterclockwise to decrease the value . Press the coding switch to shift to the left. 5 seconds after the voltage setting operation is completed, the flashing stops, and the current setting value is stored.
3. Current setting
Regardless of whether the power supply is in the output state, you can turn the "CURRENT" coding switch to set the current. When entering the current setting state, the currently set "bit" will flash in a flashing manner; turn clockwise to increase the value, and turn counterclockwise to decrease the value . Press the coding switch to shift to the left. 5 seconds after the current setting operation is completed, the flashing stops, and the current setting value is stored.
4. Output switch
Short press the "Output" button on the panel to switch the power output and shut down.
5. OCP short circuit
WPS model: Press the "CURRENT" codes switch for 3 seconds to turn on (or turn off) the OCP short circuit alarm function.

Specification:
Item Type: DC Power Supply
Material: Metal Plate+ABS
Model: WPS3010H
Purpose: Voltage Debugging
Output Voltage: 0V-30V
Output Current: 0A-10A
Output Power: 300W

Package List:
1 x DC Power Supply
1 x Power Cord
1 x Load Line
1 x Manual
