DB Electrical 340-22032 Marine Stator Coil 782cc Compatible With/Replacement For Sea-Doo GSX 1996 1997, GTX 1996-2002, XP 1996 1997 1998 1999 2000 2001 2002, SPX 1997 1998 1999 290-886-588

KWD 33.500
Weight
454 g
– 1 +

Special Features

  • Specs: Stator Coil, Voltage: 12, Dimension: 18 Posts, 35mm ID, 92.9mm OD, 27.7mm Width, (3) 6.0mm Mounting Holes, (4) Wires in Harness - (3) Yellow, (1) Black, Terminated in a 6-Terminal Deutsch Connector, Harness is 100mm From the Stator Clip to the Inside of the Connector
  • Replaces OEM Numbers: ARROWHEAD: 340-22032, BOMBARDIER: 290-886-588, 420-886-588, J & N: 340-22032
  • Compatible With/Replacement For: SEA-DOO Challenger 1996-1999, GSX 1996-1997, GSX LTD 1998-1999, GTX 1996-1997, GTX 1998-2002, LRV 2000-2001, RX 2000-2002, RX X 2001-2001, Speedster 1998-1999, Sportster 2000-2003, SPX 1997-1999, XP 1996-1997, XP 1998-2002
  • 1-year warranty protects you after your purchase. We're confident that our products will work flawlessly once installed in your vehicle. But in a rare case that it does not, we'll replace it anytime within one year of your order. If you have a problem, we will take every step to assist you, contact us for a replacement.
  • 100% New Aftermarket Stator Coil built to meet OEM specifications

Description

**Verify the part fits before purchasing**

Specs:

Unit Type: Stator Coil
Voltage: 12
Dimension: 18 Posts, 35mm ID, 92.9mm OD, 27.7mm Width, (3) 6.0mm Mounting Holes, (4) Wires in Harness - (3) Yellow, (1) Black, Terminated in a 6-Terminal Deutsch Connector, Harness is 100mm From the Stator Clip to the Inside of the Connector,
Brief: Sea-Doo PWC 1996-03
Sea-Doo Sportboats 1996-03
Used On: 1996-97 Sea-Doo GSX w/782cc PWC: 1998-99 Sea-Doo GSX LTD w/951cc PWC: 1996-02 Sea-Doo GTX w/782cc PWC: 2000-01 Sea-Doo LRV w/951cc PWC: 2000-02 Sea-Doo RX w/951cc PWC: 2001 Sea-Doo RX X w/951cc PWC: 1997-99 Sea-Doo SPX w/782cc PWC: 1996-07 Sea-Doo XP w/782cc PWC: 1998-02 Sea-Doo XP w/951cc PWC: 1996-99 Sea-Doo Challenger Sportboats: 1998-99 Sea-Doo Speedster Sportboats: 2000-03 Sea-Doo Sportster Sportboats

Replaces OEM Numbers:

ARROWHEAD: 340-22032
BOMBARDIER: 290-886-588, 420-886-588
J & N: 340-22032

Compatible With/Replacement For:

SEA-DOO Challenger 1996-1999, GSX 1996-1997, GSX LTD 1998-1999, GTX 1996-1997, GTX 1998-2002, LRV 2000-2001, RX 2000-2002, RX X 2001-2001, Speedster 1998-1999, Sportster 2000-2003, SPX 1997-1999, XP 1996-1997, XP 1998-2002
