Garosa Pneumatic Steam Valve, Air Actuated Thread Angle Seat Valve, PTEE Sealing, Stainless Steel Thickened Plastic Case Steam Valve(1/2" DN15)

KWD 12.500
KWD 14
Brand
Garosa
Category
Fittings
Weight
0.7 kg
– 1 +

Special Features

  • No water hammer, water hammer (water impact) is absorbed when fluid flows from under the valve stem, flowing rate is 30% larger than the ordinary angle seat valve.
  • The gas head can be rotated 360 degrees, and even the limit switch can be rotated 360 degrees. Easy to install one to two limit switches
  • Low-wear piston construction for easy operation and low air consumption, no internal self-lubricating.
  • Optional smaller control head when fluid flows in from above the valve stem, built-in metal connector for easy connection
  • Visual position indication, can connect limit switch or emergency manual devices, stem PTEE sealing to prevent from being introduced.

Description

Specification:
Item Type: Angle Seat ValveMaterial: Stainless steel, plastic
Standard(optional): DN15 (1/2in), DN20 (3/4in)
Connection Form: Thread
Pressure Environment: Atmospheric Pressure
Use: Commutation
Bore Diameter: 50mm
Spool Sealing: PTFE
Stem Sealing: PTFE/FKM
Piston Sealing: FKM/NBR
Applicable Medium: Water, Neutral Gas or Liquid, Alcohol, Oil, Organic Solvent, Weak Acid or Weak Alkaline Solution
Medium Temperature: PTFE: -10 ~ +180
Ambient Temperature: -10 ~ +60
Viscosity: Up To 600mm²/S
Control Medium: Air/Neutral Gas
Control Pressure Range: 0.3-1MPa
Widely Used: Beer and beverage, textile printing and dyeing, pharmaceutical and food processing, rubber machinery, organic or inorganic chemicals, high temperature sterilization, water/sewage treatment

Package List:
1 x Angle Seat Valve
