Specification:
* Model: R210-C5L-BR
* 20A 125VAC/250, 3/4HP
* 16A 125/250VAC, 1/4HP
* 10(2)A~250VAC T125/55
* 16(4)A~250VAC T125/55 (VDE, ENEC10, CQC)
* Switching Method: ON-OFF
* Initial Contact Resistance: 20m ohm max.
* Insulation Resistance: 100M ohm min, at 500VDC
* Dielectric Strength: 1,000 VAC(UL), 3000VAC(VDE)for 1 minute
* Electrical Life: 6000(UL); 10000(VDE) cycles
* UL Recognized Component, VDE & ENEC10 in Europe, CQC in Asia
* Standard 22x30mm Snap-In Cutout Size
* DPST
* Quick-connect terminals
* Built in with neon lamp
* Panel cut-out roughly 22mm x 30mm (snaps in)
* Bezel 32mm x 25mm
* One actuator
Features:
-- This is the original OEM Canal R Series switch commonly found in appliances like oven hood range fans.
-- The switch meets the highest electrical standards, and it is an ideal replacement for home appliance repair tools.
-- Snaps conveniently into appliance, contains red translucent rocker lamp, quick connect terminals, and constructed of plastic housing material.
Package Include:
* 1PC Switch
