Special Features

  • The reference source module has SMA female interface, with ultra low phase noise, reliable connection and stable performance.
  • The reference source module has SMA female interface, with ultra low phase noise, reliable connection and stable performance.
  • To replace the old, broken or damaged one with this crystal oscillator frequency reference board, to ensure stable operation of the device.
  • Suitable for instrument standard such as audio system, decoder, shortwave radio, frequency meter, source, etc., convenient and practical.
  • Using excellent PCB component, this OCXO frequency module has high calibration accuracy, good frequency stability and low loss.
  • Industrial supplies, electrical and electronic components, modules

Description

Specification:
Item Type: Frequency Standard Reference Module
Current Consumption: Preheating stage Warm Up Time: About 5 minutes
Calibration Accuracy: ±0.01Hz
Frequency Stability: 5e-12
Output Level:
DBm: 10dBm±2dBm at 50Ω;
VRMS: 0.7071V at 50Ω;
VPeak: 1.0V at 50Ω;
P: 2.0V at 50Ω
Output Impedance: 50Ω
Interface Type: SMA Female
Product Use: Constant temperature 10MHz, ultra low phase noise, frequency reference module, frequency reference source, OCXO frequency reference source, used for instrument benchmarks such as audio systems, decoders, shortwave radios, frequency meters, sources, etc.

Package List:
1 x Module
1 x Cable
