JRready ST6418 Standard.093 Pin and Socket Power Connectors 6 Circuits (5 Matched Sets), 14-20 AWG，Compatible with Molex Standard.093 6 Pin Male& Female Conector, 5.03 mm Pitch, Free Hanging

KWD 6
Brand
JRready
– 1 +

Special Features

  • Package List：6 pin male and female connector housing 5 pairs, pin and sockets 35 pairs, total 80 PCS.
  • Description: 2.36mm diameter standard .093" pin and socket receptacle housing, 6 Circuits, 5.03 pitch, without mounting ears,free hanging
  • Housings: made of high quality PA66 material，sturdy and durable，high and low temperature resistance -40-105℃.
  • Contacts: Brass tin plated material, high temperature resistance,corrosion resistance,high conductivity, wire range 14-20 AWG, rated current 12A.
  • Compatible Molex Models: Connector Housings:03091064 / 03092062, contacts pin: 02092101 / 02092103，socket: 02091102 / 02091104.
  • Application：Standard 0.093"(2.36mm) Pin and Socket, Wire to Wire Connection are ideal for consumer, networking, and data/communications applications.
