230V 100A AC Contactor,2P / 2NO Main Contacts Modular Contactor,Extra Long Life,Ultra Quiet,Energy Saving,for Vast Majority Of Building Electrical Control

KWD 13.500
Brand
Jectse
Weight
310 g
SizeAC230V
– 1 +

Special Features

  • EXTRA LONG LIFE: Extra long life, withstand 100,000 full load switching under AC-7a load type.
  • ULTRA-SILENT: Ultra-silent, this product eliminates the obvious impact sound of the traditional contactor at the moment of suction, and eliminates the low-frequency buzz in the work of the contactor. It is suitable for the vast majority of building electrical control
  • ULTRA-ENERGY-SAVING: Ultra-energy-saving, contactor in working state, need to maintain a long period of power-on to keep the coil suction, in this process need to consume a lot of electricity. The contactor reduces the maintained power of the contactor greatly by optimizing
  • OPERATING FREQUENCY: The rated operating frequency of contactor under this working system is 30 times/h and the load factor is 40%.
  • ADVANTAGE: In the ambient air temperature range of - 5 +60℃, when rated control power supply voltage Us is applied to the contact attraction coil to make it heat to stable state, the contactor should be able to close reliably at any voltage in the range of (85%-11

Description

Specification:
Rated current: 100A (AC-7a)
Conventional heating current(lth): 63A
Rated control power supply voltage(Us): 24V AC; 230V AC (Optional)
Rated insulation voltage(Ui): 500V AC
Rated operating voltage(Ue): 250VAC
Number of main contacts: 2P, 2NO
Electrical life (time): 100000
Mechanical life (time) : 1000000
Maximum switching operation times: 1h/30

Package list:
1 * AC Contactor

Note:
The actual product color may deviate from the photo due to light.
There may be a slight deviation in the measurement of product.
