Parameter
Voltage:DC12V
Operation mode:N/C,normal close.
Inlet/Outlet Ports:1" to 1",GB screw thread
Response Time:ON≤0.15s,OFF≤0.3s
Rectification: synchronous rectification
Pressure:0.02-0.8Mpa
Temperature:0-75°C
Estimated Valve Life:500,000 Cycles
Filter Screen:Stainless Steel Inlet Filter
Flow characteristic:0.02Mpa≥3 L/min;0.1Mpa≥12 L/min;0.8Mpa≥35 L/min
Usage:water and low viscosity fluids.
