Model: HSC20-3.2MM
Sensor: Sony IMX577 Exmor R CMOS 1/2.3”
Resolution: 12MP
Record video resolution: 3840*2160@30FPS / 2560*1440@30FPS / 1920*1080@60FPS / 1920*1080@30FPS / 1280*720@60FPS / 1280*720@30FPS
Video Format: MP4
HDMI output: 2160P/30/25/24fps, 1080P60/50/30/25/24fps, 1080i60/50fps, 720P60/50fps Different monitors or HDMI receivers support part of resolutions only. (For example, A 1080P monitor cannot display 4K resolution)
SDI output: 1080P60/50/30/25/24fps, 1080i60/50fps, 720P60/50fps
External microphone : Support ( Record video to TF card only )
USB output: 1920*1088@30FPS / 1920*1080@30FPS / 1280X720@30fps / 640X480@30fps
Support system: Windows / OS X / Linux
Audio: Record video / Video Playback / USB Mode with Audio / HDMI Real-time output without Audio
Time Lapse: 0.25s, 0.5s, 1s, 2s, 5s, 10s, 30s, 60s, 2minutes, 5minutes, 30minutes, 1hour
Burst: 0.25s, 0.5s, 1s, 2s, 5s, 10s, 30s, 60s, 2minutes, 5minutes, 30minutes, 1hour
Digital Zoom: Support ( 4K HMDI output not support )
Remote control: Support ( HDMI or SDI Mode ), USB Mode for EV and Digital Zoom function only
Power On: Auto Power On when plug ac adapter, Press camera “ON / OFF” button power on
Power Off: Long press camera “ON / OFF” button power off， Remote control Power off
Lens Mount: C/CS
Exposure: AUTO / Manual
ISO: Auto / Manual (100~1600)
Electronic shutter: Auto / Manual (1/10~1/2000S)
EV: Support 12 Level manual Settings
White Balance: AUTO / Manual
Storage: Support 256GB(Max) TF card, Fat32 or Exfat only
Power Mode（HDMI / SDI）: DC 12V 1A
Loop Recording: 3 / 5 / 10 mins each document Loop recording and OFF (15 mins each document at 4K)
Image Orientation Change: Support screen rotation 180 degrees and Mirroring
Camera Size（Without lens）: 100*60*60MM
Product Weight（Without lens）: 230g
