Features
* Wide 5V to 65V Operation Voltage
* Output Adjustable from 1.25V to 25V
* Maximum Duty Cycle 100%
* Minimum Drop Out 1V
* Fixed 200KHz Switching Frequency
* Maximum 0.5A Output Current
* Recommend output power less than 8W
* Internal Optimize HV Power Transistor
* High efficiency up to 85%
* Excellent line and load regulation
* TTL shutdown capability
* Built in thermal shutdown function
* Built in output short Protection Function
* Built in current limit function
* SOP8-EP (Exposed PAD) package

Applications
* Ebike Controller Power Supply
* Telecom / Networking Equipment

Description
The XL7005 is a 200KHz fixed frequency PWM buck (step-down) DC/DC converter, capable of driving a 0.5A load with high efficiency, low ripple and excellent line and load regulation. Requiring a minimum number of external components, the regulator is simple to use and include internal frequency compensation and a fixed-frequency oscillator.
