Product parameters
Body: ABS (fire resistant) black
Contact capacitance: 0.7PpF
Contact form: 1A (SPST-NO)
Insulation resistance: 10 ^ 10Ohms
Contact position: SYM
Resonant frequency: 4KHz
Contact material: Ru
Working temperature: -10 ° C~85 ° C
Contact resistance (initial): 100mOhms
Working frequency max: 100 Hz
Insulation resistance min: 150 Vdc
High voltage resistance: 220VDC (AT25)
Release value: 5
Action time: 1.0mSec. (Max)
Electrical life: 10 ^ 8 (5v, 10mA)/10 ^ 5 (24V, 400mA)
Release time: 0.4mSec. (Max)
Collapse voltage min: 150V
Pin wire: gold/silver corner
