Characteristics:
16A 1/2HP 125 250VAC, 0.6A 125VDC, 0.3A 250VDC
Operating frequency: Mechanical: 240 operations/min, Electrical 20 operations/min
Insulation resistance: 100mOhm above(@ 500VDC)
Contact resistance: 15mOhm max.(initial value)
Vibration: 10 to 55Hz, 1.5mm pairs swing
Shock Durable: 1,000m/S², Misoperation: 300m/S²
Mechanical Life: 10,000,000
