CanMV-K230 specifications:
SoC – Kendryte K230CPU64-bit RISC-V processor @ 1.6GHz with RISC-V Vector Extension 1.0, FPU 64-bit RISC-V processor @ 800MHz with support for RV64GCB instruction set;

AI acceleratorKPU with support for INT8 and INT16 Compatible with TVM, TensorFlow, Pytorch, ONNX
Typical network performance: Resnet 50 ≥ 85fps @ INT8; Mobilenet_v2 ≥ 670fps @ INT8; YoloV5S ≥ 38fps @INT8;

“DPU” using 3D structured light depth calculation up to 1280×800 @ 30fps
VPU – Video encoding/decoding for H.264/H.265/JPEG/MJPEG up to 4Kp40/4Kp20

System Memory: 512MB LPDDR3
Storage – QSPI flash, microSD card slot
Display – HDMI port, MIPI DSI connector up to 1080p60
Audio – 3.5mm audio jack
Camera – Up to 5MP camera, up to 3-ch MIPI CSI inputs
Networking
10/100Mbps Ethernet RJ45 port
WiFi 4 and Bluetooth 4.0 via AP6212 wireless module USB – 1x USB 2.0 OTG Type-C port port
Expansion – 40-pin GPIO header with up to 29x GPIOs, 5x PWM, 4x I2C, 2x UART
Misc – Buttons, RGB LED
Power Supply – 5V via USB-C port
Dimension – 85 x 56 mm
Support:
Forum: forum.youyeetoo.com (recommended)
Communication and personal advice:
am2#youyeetoo.com (#>>@)
