Waveshare ESP32-S3 1.69inch Round Display Development Board, Embedded with ST7789V2 Display Driver Chip, SPI Display, 32-Bit 240MHz LX7 Dual-Core Processor, Round Micro LCD Display

✅Equipped with ESP32-S3R8 Xtensa 32-bit LX7 dual-core processor, up to 240MHz main frequency. Supports 2.4GHz Wi-Fi (802.11 b/g/n) and Bluetooth 5 (LE), with onboard antenna
✅Built in 512KB of SRAM and 384KB ROM, with onboard 8MB PSRAM and an external 16MB Flash memory. Type-C connector, keeps it up to date, easier to use. Onboard 1.69inch 240×280 pixels 262K display for clear color pictures
✅Built-in ST7789V2 display driver chip, using SPI communication, effectively saving the IO resources. Onboard QMI8658 6-axis IMU (3-axis accelerometer and 3-axis gyroscope) for detecting motion gesture, counting steps, etc.
✅Onboard PCF85063 RTC chip with reserved SH1.0 RTC battery header (supports charging) for RTC function requirement. Onboard RST, BOOT and a programmable PWM button for easy custom function development
✅Onboard 3.7V MX1.25 lithium battery recharge/discharge header. Reserved 12PIN header of 5 × GPIO, I2C, and UART interfaces, for connecting peripherals and debugging. Supports flexible clock, module power supply independent setting, and other controls to realize low power consumption in different scenarios
❤️Rich WiKi Resources❤️ We provide official Wiki resources, please contact us for more information.
