Features at a Glance

Adopts MCP2515 and SN65HVD230 dual chips combined solution, allows 2-channel CAN communication
Integrated power isolation, providing stable isolated voltage, requires no extra power supply for the isolated terminal
Onboard digital isolator, signal isolation makes the communication more safe, more stable, and better anti-interference
Onboard TVS (Transient Voltage Suppressor) diode, provides ESD protection and transient peak voltage protection
Onboard voltage translator, select 3.3V/5V operating voltage by jumper
Onboard 120Ω terminal resistor, configured by jumper
Breakout SPI control pins, for connecting with host control boards like STM32/Arduino

Package Content

1. 2-CH CAN HAT x1
2. Standoffs pack (2pcs) x1
3. 2×20PIN female header x1
