100 Pcs 12-10 AWG Insulated Ring Terminals, Brazed Seam Non-Insulated Copper Wire Connectors,5/16in RV5.5-8 Copper Electrical Wire Crimp Connectors for Automotive, Audio

KWD 5
Brand
Buachois
– 1 +

Special Features

  • APPLICABLE TYPE: Ring Insulated Terminals are rated for 48A and are suitable for crimping 4‑8mm² (AWG 12‑10) wire. The applicable crimping tool is HX-30J AN-30J AP-30J FSB-054YJ.
  • 100PCS SET: Includes 100pcs insulated wire terminals, with ring design, easy to connect, not easy to l-eak, durable, lightweight and compact. Sufficient quantity to meet your needs.
  • CONVENIENT AND PRACTICAL: The terminals can be easily crimped, and the durable insulated crimp terminals are ideal for hard-to-crimp solid or stranded wires.
  • MATERIAL: These Ring Insulated Terminals are made of high quality red copper and PVC material with good insulation and conductivity. The stability of the wire connection is guaranteed.
  • APPLICATIONS: Insulated ring terminals are widely used in the electrical and electronic industry, electrical equipment, machinery, electricity, transportation lighting, home appliances, computers or other automation equipment.

Description

Specification:
Item Type: Insulated Wire Terminal
Model: RV5.5-8
Material: Copper + PVC
Color: Yellow
Applicable Wire: 4-8mm²(AWG 12-10)
Maximum Current: 48A
Applicable Crimping Tool: HX-30J AN-30J AP-30J FSB-054YJ
Bolt Diameter: Approx. 8mm / 0.31in
American Bolt: 5/16in
d2: 8.5mm / 0.33in
W: 15mm / 0.59in
F: 13.5mm / 0.53in
L: 34mm / 1.34in
H: 13mm / 0.51in
d1: 3.5mm / 0.14in
D: 6.5mm / 0.26in
T: 1mm / 0.04in

Package List:
100 x Terminals
