Compatible with Socapex "419" and Veam "VSC" connectors.
Rugged die-cast aluminum alloy shells with black non-conductive finish.
Hard gold plated contacts in solder version.
Integral compression-type strain relief handles wide range of cable size.
Rated Voltage: AC110-120V, 220-240V
Max. Load Current: AC 20A 220V
Operating Limit Voltage: AC 400V
Dielectric Strength Test: 1,800 VAC / Min
Insulation Test: > 500MΩ
Contact Resistance: Terminal Wear Test: Over 5,000 operations
Operating Temperature: -20 + 85 degree C
Body Material: Aluminum ally
IP Rating: IP66
Certification: CE
