Overview
RP2040-PiZero is a high-performance and cost-effective microcontroller board designed by Waveshare, onboard DVI interface, TF card slot and PIO-USB port, compatible with Raspberry Pi 40PIN GPIO header, easy to develop and integrate into the products.

Board specifications
--RP2040 microcontroller chip designed by Raspberry Pi in the United Kingdom
--Dual-core ARM Cortex M0+ processor, flexible clock running up to 133 MHz
--264KB of SRAM, and 16MB of onboard Flash memory
--Onboard DVI interface can drive most HDMI screens (DVI compatibility required)
--Supports using as a USB host or slave via onboard PIO-USB port
--Onboard TF card slot for reading and writing TF card
--Onboard Lithium battery recharge/discharge header, suitable for mobile scenarios
--USB 1.1 with device and host support
--Drag-and-drop programming using mass storage over USB
--Low-power sleep and dormant modes
--2 × SPI, 2 × I2C, 2 × UART, 4 × 12-bit ADC, 16 × controllable PWM channels
--Accurate clock and timer on-chip
--Temperature sensor
--Accelerated floating-point libraries on-chip
--8 × Programmable I/O (PIO) state machines for custom peripheral support

Package Content
RP2040-PiZero x1

NOTE: Online Development Resources and Technical Support are provided, please feel free to contact us if you have any problem!
