10 Blade Whistle Turbine Wheel Rebuild Kit for 05-07 6.0 3782 Turbo

KWD 47.500
Weight
0.6 kg
– 1 +

Special Features

  • Upgrade 64mm 10 blade ultra flow turbine wheel flows more exhaust gas and provide excellent turbo whistle
  • 360º thrust bearing vs. stock 270º thrust bearing enhances turbochargers durability
  • Stragged step gap piston rings on both sides reduce the likeness of oil leakage from the center housing to compressor or turbine stage
  • Drop-in upgrade design, no modifications needed.
  • Compatible with 2005-2007 6.0L GT3782VA turbo ONLY. Be aware that this kit does not fit 03 6.0L Powerstroke trucks, check turbine wheel size(64mm) before purchasing.

Description

-Application:
Stock turbo parts Fitment - No modifications required.
Compatible with2005-2007 6.0L Stock GT3782VA Turbo ONLY

-Turbine Wheel:
Blades: 10
Inducer: 72.7mm
Exducer: 64mm
Tip Height: 14.5mm
Journal Dia: 11.5mm
Stem Dia: 7.50mm M7x1.00 LHT
Reference Part #: 743250-0014

-This rebuild kit contains:
1*10 Blade Turbine Wheel (64mm Drop-in)
1*Seal O-Ring
1*360 Degree Thrust Bearing
1*Thrust Collar
1*Thrust Spacer
3*Seal Plate Bolt
2*Journal Bearing
1*Bearing Spacer
1*Small Seal O-Ring
5*Housing Bolt
1*Compressor End Seal Ring
1*Turbine End Seal Ring

-Special Note:
1. Professional installation is highly recommended! Please ask all questions prior to purchase!
2. Highly recommended to get the CHRA VSR balanced after rebuild (is required for warranty purposes)!
