Specification:
REX-C100 thermostat
Model no. : rex-c100fk07-v *AN
Measurement accuracy: 0.5% FS
End to end compensation tolerance:±2℃ (can be modified by software in 0~50℃)
Resolution: 14 bits
Sampling cycle: 0.5 seconds
Power supply: AC 110-240v 50/60hz
Process value (PV), set value (SV)
Output, alarm and self-setting can be indicated : by LED
PIN control (including ON/OFF, stepper PID and continuous PID)
Self-adjusting control
Delayed output: contact capacity 250V AC 3A (resistance load)
Alarm function output: 2 channels
Proportional band (P) : 0 ~ full range (ON/OFF control set to 0)
The testing temperature range: 0 ~ 1300℃
Insulation resistance: > 50M ohm (500V DC)
Insulation resistance: 1500V AC/min
Insulation resistance: power consumption
The environment of service: 0 ~ 50℃
Non-corrosive gas environment 30 ~ 85% RH
Appearance size: 48*48*110mm
Two, K thermocouple probe cable
Length: 1 m
Diameter of sensor: 4.5mm
Temperature range: 0 ~ 400℃
Internal insulation: glass fiber
External shielding: insulation shielding
Maximum 40A SSR (solid state relay)
Output voltage range: standard
Output current: 40A
Input voltage: DC 3-32v
Output voltage: 24-380v AC
Weight: 265 g / 9.3 oz(approx.)

Package list:
1 x REX-C100 PID temperature controller
1 x K thermocouple/temperature sensor
1 x Max 40A SSR
