Features:
This programmable logic controller uses industrial-grade 32-bit MCU with strong anti-interference and faster speed.High quality chip, stable performance, on-line download, on-line monitoring, automatic save when power off.Program is written in ladder logic programming language, supports for GX-Developer, GX-work2, supports HMI connection.Programming port is the port for program upload, download and HMI communication.Original password protection, as long as the password is 12345678, inner program will be protected from being stolen. At this time there is no program reading function, only can download program and "parameter" option cannot be ticked when download. Unable to unlock the password.The PLC transmission baud rate is 9600.

Specifications:
Output Type Relay output
Memory Capacity 8000steps
Power Supply Voltage DC24V
Output Current 5A
Analog Input No
Analog Output No
High Speed Input 2 Channels 3K
High Speed Output No
RS485 Communication Support
For MODBUS Support
Connection to Text Display Support
Connection to Touch Display Support
Programming Software GX Developer or GX Works2
Size 87.5*92mm/3.44*3.62"

Package Includes:
1 x PLC
