Product_Title: 5 x PEEK Hex Socket Head Screws M6 x 20mm Nuts & Bolts - Peek Plastic nuts and bolts, anti corrosion, chemical resistant, high temperature resistance, (15/64 x 25/32 in).

Please refer to the technical image for size details. All measurements are in millimetres/millimeters.
||
- Product Specifications -
||
Product_SKU: AC-H456-ZRT8.
Product_Type: Socket Head Bolts.
Product_Size: M6 x 20mm.
Product_Color: Natural.
Product_Quantity: 5 Pack.
Product_Pitch (mm): 1mm.
Product_Length (mm): 20mm.
Product_Width (mm): 6mm.
Product_Depth/Thickness (mm): 6mm.
||
- Reference Details -
||
Primary_Material: PEEK / Polyether ether Ketone.
Type_Reference: Socket Head Bolts.
||
Product_Pitch (inches): 0.04 inches.
Product_Length (inches): 0.79 inches.
Product_Width (inches): 0.24 inches.
Product_Depth/Thickness (inches): 0.24 inches.
||
- Additional Specifications -
||
Nut Product Image Drawing References: Stock Code: CR06359PEEK , Material: Polyether ether ketone , Material Reference: PEEK/HN , Head/Drive Type: Hexagon Nut , Overall Size: M6 , N (mm): M6 , HN B: 9.89 , HN H: 5.05 ,.
||
Bolt Product Image Drawing References: Stock Code: CR01635PEEK , Material: Polyether ether ketone , Material Reference: PEEK/S0 , Head/Drive Type: Socket Hex Head Bolt , Overall Size: M6 x 20 , Metric Size: M6 , D: 6.0 , Pitch: 1.0 , L: 20 , HD: 10.0 , HH: 5.85 , HS: 5.08 ,.
||
- Additional Description - Anti corrosion, chemical resistant, high temperature resistance, non-expanding. Offers hydrolysis resistance to steam, water, and sea water. PEEK has the ability to maintain stiffness at high temperatures and is suitable for continuous use at temperatures up to 338oF (170oC). This engineering plastic has a proven track record in challenging environments such as aerospace, oil and gas, and semiconductor..
||
