Descriptrion:
Operating ambient temperature: -25 ℃ ~ +55 ℃
Standard sensing object: less sunlight 10000LX incandescent 3000LX
Diameter: 18mm ( 23/32 in )
Sensor length: 45mm ( 1 25/32 in )
Lead Length: 50cm ( 10 1/4 in )
Red: connected 4.5-5V power supply high
Yellow: connected microcontroller output TTL level to the microcontroller
Green: GND 0V power low
Electrical Characteristics:
U: 5VDC
I: 100Ma
Sn :3-80CM
Appearance: Threaded cylindrical
Material: Plastic
Guard mode: Reverse polarity protection
Ambient temperature: -25-70 ℃

Package Included:
1 x E18-D80NK Sensor
