Features:
Material:PPS UL.94-V0, Thermoplastic,Color:Black
Protection class:IP66
Nut material:Nut - steel (galvanized), self-locking
Stud Material:Stainless Steel
Lid Material:Plastic; Color: Red
Insulation Material:Ceramic
Fuse Material:Copper Alloy (Nickel Plated) Thickness: 2.5mm, Color: Silver
Fuse Housing:PES Plastic, Color: Clear
Stud Size:M8 (5/16")
Fuse Box Mounting Hole Size:3/8" (M10)
Isolated stud design uses standard M8 hardware and permits stacking of terminals.
10,000 AIC at 14V DC satisfies ABYC requirements for DC Main circuit protection on large battery banks
WARNING: Do not mount fuses directly on battery terminals. Must use with Terminal Fuse Blocks
