GFCI is a high-sensitivity, fast-response leakage protection device, which can quickly cut off the circuit and isolate the fault point when a dangerous ground fault leakage occurs, so as to avoid the occurrence of electrical accidents and ensure personal safety. The working principle of GFCI is that when there is equipment leakage or human body gets an electric shock, part of the current flows into the ground, and when the current flowing through the live wire and the neutral wire is not equal (the normal situation is equal), the GFCI monitors the current difference between the live wire and the neutral wire. Once the difference is greater than 6mA, the power supply can be cut off at the moment of 0.025 seconds, so as to ensure the safety of people and property. Widely used in homes, offices, hospitals, schools, hotels, factories and other outdoor venues. Specification:
Grounding: Standard Grounding
Rated Voltage: 125V
Rated Current: 15A/20A
Application: Residential/General-Purpose
Electrical Characteristics: AC125V/15A/20A
Color:White
Unloaded plug≥5000Sec Loop detection with automatic monitoring function
Meet the standard:UL,CUL
Housing material flame retardant grades
Tripping threshold:5mA Tripping time
Surge current:6000V/3000A 6000V/10KA
Electric strength:Pressure resistance1500V 50Hz Duration 1Min
Insulation resistance:>50MΩ(DC500V)
Short-circuit current:10KA
Insert and Draw Frequency>10000 times
Temperature,humidity:-35℃ ~ +66℃; 20% ~ 90%
Storage Temperature,Humidity: -20℃ ~ +85℃; 10% ~ 95%RH
