Applications
The boost module can be used in smart home, player, camera, surveillance, wireless network/communication equipment, industrial equipment, etc. to provide stable voltage output.

Specification
Input Voltage: 0.9-5V.
Output Voltage: 5V.
Input:1-1.5V, Output:5V 40-100MA.
Input:1.5-2V, Output:5V 100-150MA.
Input:2-3V, Output:5V 150-380MA.
Input above 3V, Output:5V 380-480MA.
Working frequency:150KHZ.
Working efficiency:85%.
Size: 11 x 11 x 7.5 mm.

Package Including
10 x Boost Converter Module

Note
1.The input voltage cannot be greater than the rated voltage when using, otherwise the module will be burned.
2.The input power must be greater than the output power, otherwise the output voltage will be less than the rated voltage.
