Universal Epaper Driver E-paper Driver Board Supports Various Waveshare SPI E-Paper Raw Panels Compatible Raspberry Pi 4B+ 4B 3B+ 3B 2B+ Zero W WH Jetson Nano

This is a universal e-paper raw panel driver HAT, can be used to drive various SPI interface e-Paper from Waveshare.
This epaper driver board with standard Raspberry Pi 40PIN GPIO extension header, supports Raspberry Pi series boards, Jetson Nano
The e-paper driver HAT is SPI interface, for connecting with other controller boards like Raspberry/Ardui/Nucleo, etc
The e-paper panel driver HAT has onboard voltage translator, compatible with 3.3V/5V MCUs
Comes with development resources and manual (examples for Raspberry Pi/Ardui /STM32), feel free to contact us if you need any technical support, we are always ready to help.

Overview

This is a universal driver board for e-Paper raw panels, can be used to drive various SPI interface e-Paper from Waveshare.

Specifications

Operating voltage: 3.3V~5V
Interface: 3-wire SPI, 4-wire SPI
Outline dimension: 65mm × 30.2mm
Mounting hole size: 3.0mm

Package include

Note: e-Paper and Raspberry Pi are NOT included.

1. e-Paper Driver HAT x1
2. RPi screws pack (2pcs) x1
3. PH2.0 20cm 8Pin x1
