Camera
Image Sensor: 1/2.8" Progressive Scan CMOS
Max. Resolution: 3840 × 2160
Min. Illumination: Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR

Lens
Lens Type: Varifocal lens, motorized lens, 2.7 to 13.5 mm
FOV: horizontal FOV 107° to 32°, vertical FOV 56° to 18°, diagonal FOV 128° to 37°
Lens Mount: Ø14
Iris Type: Auto-iris
Aperture: F1.6

DORI
D: 88 m to 273 m, O: 35 m to 108 m, R: 17 m to 54 m, I: 8 m to 27 m

Illuminator
Supplement Light Range: Up to 60 m
Supplement Light Type: IR

Wide Dynamic Range (WDR): 120 dB
SNR ≥ 52 dB
Image Enhancement: BLC, HLC, 3D DNR
Privacy Mask: 8 programmable polygon privacy masks

Interface
Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port
Audio: 1 input (line in); 1 output (line out)
On-Board Storage: Built-in memory card slot, up to 512 GB
Alarm: 1 input, 1 output (max. 24 VDC/24 VAC, 1 A)
Built-in Microphone: Yes
Reset Key: Yes

Event
Basic Event: Motion detection (human and vehicle targets classification), video tampering alarm, exception
Smart Event: Unattended baggage detection, object removal detection, loitering detection, people gathering detection, people running detection, parking detection, video quality diagnosis
Linkage: Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,trigger capture

Deep Learning Function
Face Capture: Yes
Perimeter Protection: Line crossing, intrusion, region entrance, region exiting

General
Power: 12 VDC ± 25%, 1.08 A, max. 13 W, Ø5.5 mm coaxial power plug; PoE: IEEE 802.3at, Class 4, max. 15 W
Material: Aluminum alloy body
Dimension: 13.1" × 3.9" × 3.7"
Weight: 3.4 lb
Protection: IP67, IK10
