Camera
Image Sensor: 1/2.9" Progressive Scan CMOS
Max. Resolution: 2688 × 1520
Min. Illumination: Color: 0.005 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR

Lens
Lens Type: Fixed focal lens, 2.8mm
Focal Length & FOV: 2.8 mm, horizontal FOV 104°, vertical FOV 57°, diagonal FOV 122°
Aperture: F1.6

DORI
DORI: D: 63 m, O: 25 m, R: 12 m, I: 6 m

Illuminator
Supplement Light Type: IR, White Light
Supplement Light Range: Up to 40 m
Smart Supplement Light: Yes

Video
Main Stream: 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720); 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
Video Compression: H.265/H.264/H.264+/H.265+
Region Of Interest (ROI): 1 fixed region for main stream and sub-stream
Target Cropping: Yes

Audio
Audio Compression: G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
Audio Sampling Rate: 8 kHz/16 kHz/32 kHz/48 kHz
Environment Noise Filtering: Yes

Image Parameters Switch: Yes
Wide Dynamic Range (WDR): 120 dB
SNR ≥ 52 dB
Image Enhancement: BLC,HLC,3D DNR
Privacy Mask: 8 programmable polygon privacy masks

Interface
Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage: Built-in memory card slot, up to 512 GB
Reset Key: Yes
Microphone: Arrayed dual-microphone

Event
Basic Event: Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception

Deep Learning Function
Perimeter Protection: Line crossing, intrusion

General
12 VDC ± 25%, 0.5 A, max. 6 W,reverse polarity protection,Ø5.5 mm coaxial power plug; PoE: IEEE 802.3af, Class 3, max. 7.5 W
Material: Metal
Dimension: Ø74.4 mm × 176.3 mm (Ø2.93" × 6.94")
Weight: 515 g (1.1 lb.)
