40W/Pack of 2

KWD 10.500
Brand
DROK
Weight
46 g
Size40W / Pack of 2
– 1 +

Special Features

  • 【Parameter】Input Voltage: DC 6.0-36V, Output Voltage: DC 0.5-36V, Output Current: 0-4.5A, Output Power: 40W, Voltage Resolution: 0.01V, Current Resolution: 0.001A, Voltage Accuracy: ±0.3% + 3 words(Calibratable), Current Accuracy: ±0.5% + 3 words(Calibratable), Conversion Efficiency: 88%
  • 【New Version LCD Screen】 Bigger and clear color LCD Display Screen prevents missing segments after long time use. Futher more, it protects circuit board pads from oxidation, improves PCB conductivity and reduces line impedance and contact resistance
  • 【Soft and Durable Button】 Silicone buttons are soft and comfortable to the touch. Compared to mechanical buttons, they can withstand prolonged use and frequent presses without wear and tear or failure, and are more durable and have a longer service life.
  • 【Protection】DROK DC buck boost converter has built-in buzzer for multi-protection alarm alerts. Input Anti Reverse Connect Protection, Output Anti Backflow Protection, Under Voltage Protection, Over Voltage Protection, Over Current Protection, Over Power Protection, Over Temperature Protection, Over Time Protection, Over Capacity Protection, Over Energy Protection.
  • 【Long Time Warranty】Since you purchase this item, you will have 1 year long time warranty.

Description

DROK Buck Boost Converter 36V 4.5A 40W
Parameter
Input Voltage: DC 6.0-36V
Output Voltage: DC 0.5-36V
Output Current: 0-4.5A
Output Power: 40W
Voltage Resolution: 0.01V
Current Resolution: 0.001A
Voltage Accuracy: ±0.3% + 3 words (Calibratable)
Current Accuracy: ±0.5% + 3 words (Calibratable)
Conversion Efficiency: 88%
Soft Start: Yes

Protection
Input Anti Reverse Connect Protection: Yes
Output Anti Backflow Protection: Yes
Under Voltage Protection: Default 5.5V (5.5-35V Adjustable)
Over Voltage Protection: Default 37V (0.5-37V Adjustable)
Over Current Protection: Default 4.6A (0.001-4.6A Adjustable)
Over Power Protection: Default 41W (0.01-41W Adjustable)
Over Temperature Protection: Default 60℃（(30-99℃ Adjustable)）
Over Time Protection: Default OFF (1-99 hours and 59 minutes Adjustable)
Over Capacity Protection: Default OFF (0.001-9999Ah Adjustable)
Over Energy Protection: Default OFF (0.001-4000KWh Adjustable)
