Access Control System Features
Access Control System FeaturesCompatibility: This device is compatible with a variety of access control components, including E/M locks, access controllers, exit push buttons, and RFID readers.
Output Configuration: It offers the flexibility to set outputs to either Normally Closed (NC) or Normally Open (NO) configurations, enabling management of a wide array of electric lock systems.
Relay Control Circuit: The lock's opening time can be adjusted from 0 to 15 seconds based on a relay control circuit. For electric controlled locks, it is advised to set the opening time to 0 seconds to prevent damage to the lock.
Automatic Protection: The system includes automatic protection against overload, over voltage, and short circuit conditions, ensuring the safety and longevity of the device.
Protection Mechanism: In case of dangerous situations, the power may be temporarily disconnected or an auto-insurance fuse may trigger to provide additional security.
Suitable Applications: Ideal for building intercom systems, various entrance access controls, and particularly suitable for all types of electric locks.
Remote Module Interface: Features a built-in remote module interface for direct insertion of a remote control module, allowing for keyless entry from a distance.
Product Specifications table { width: 100%; border-collapse: collapse; } th, td { border: 1px solid #ddd; padding: 8px; text-align: left; } th { background-color: #f2f2f2; } .specification-title { color: #333; font-size: 24px; margin-bottom: 10px; } .package-list { list-style-type: none; padding: 0; } .package-item { padding: 5px 0; } Product Specifications Power Supply Unit Specification Details Input Voltage AC 110-240V (Worldwide voltage) Input Frequency 50-60Hz Output Voltage DC 12V Output Current 5A Power 50W Operating Temperature -20°C to 65°C Adjustable Locking Delay 0-15sec Dimensions 210Lx166Wx70H(mm) / 8.27Lx6.54Wx2.76H(inch) Weight 1.0KG Package Contents1 x Power Supply
1 x User Manual
