Camera
Pixel: 5MP
Image Sensor : 5MP CMOS
Max. Resolution: 2880 (H) × 1620 (V)
Scanning System:Progressive
Electronic Shutter Speed: PAL: 1/3 s–1/100000 s ; NTSC: 1/4 s–1/100000 s
Minimum Illumination: 0.001 lux@F1.0 (Color, 30 IRE) ; 0.0001 lux@F1.0 (B/W, 30 IRE) ; 0 lux (Illuminator on)
S/N Ratio: >65dB
Illumination Distance: IR: 40 m (131.23 ft) ; Warm light: 40 m (131.23 ft)
Illuminator Control:Auto/ Manual
Illuminator Number : 2 (IR light) ; 2 (Warm light)
Lens
Lens Type: Fixed-focal
Lens Mount : M12
Focal Length: 2.8 mm; 3.6 mm
Max. Aperture: F1.0
Field of View: 2.8 mm: H: 111°; V: 57°; D: 131° / 3.6 mm: H: 89°; V: 47°; D: 104°
Iris Control: Fixed
Close Focus Distance : 2.8 mm: 1.5 m (4.92 ft) ; 3.6 mm: 2.2 m (7.22 ft)
Port
Video Output : Video output choices of CVI/TVI/AHD/CVBS by one BNC port
Audio Input : One channel built-in MIC
Video
Resolution : 5M (2880 × 1620);4M (2560 × 1440);1080p (1920 × 1080); 960H (960 × 576/960 × 480)
Electrical
Power Supply: 12 VDC ± 30%
Power Consumption: Max 5.7 W (12 VDC, LED on)
