Camera
Image Sensor: 1/1.8" CMOS
Max. Resolution: 2688 (H) × 1520 (V)
RAM/ROM:256 MB/128MB
Scanning System:Progressive
Electronic Shutter Speed: Auto/Manual 1/3 s–1/100,000 s
Minimum Illumination:0.0005 lux@F1.0
S/N Ratio:More than 50dB
IR Distance: Up to 50 m (164.04 ft) (Warm light)
Illuminator Control:Auto/ Manual
Illuminator Number : 4 (Warm light)
Lens
Lens Type: Fixed-focal
Lens Mount : M16
Focal Length: 2.8 mm; 3.6 mm
Max. Aperture: F1.0
Field of View: 2.8 mm: H: 112°; V: 60°; D: 134° / 3.6 mm: H: 94°; V: 50°; D: 113°
Iris Control: Fixed
Close Focus Distance : 2.8 mm: 1.7 m (5.58 ft) ; 3.6 mm: 2.6 m (8.53 ft)
Intelligence:IVS (Perimeter Protection),SMD Plus,Smart Search.
Audio
Built-in MIC : Yes, built-in Mic
Compression: G.711a; G.711Mu; PCM; G.726
Network
Ethernet: RJ-45 (10/100 Base-T)
Network Protocol : IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; P2P; Bonjour; Auto Registration
User/Host : 20 (Total bandwidth: 48 M)
Storage : FTP; SFTP; Micro SD card (support max. 256 GB); NAS
Browser : IE; Chrome; Firefox
Management Software: Smart PSS Lite; DSS; DMSS
Smart Phone:IOS, Android
Electrical
Power Supply:12 VDC; PoE
Power Consumption: Basic: 2.0 W (12 VDC); 3.0 W (PoE);Max.: 5.6 W (12 VDC); 7.2 W (PoE) (H.265+ intelligence on + WDR + illuminator intensity)
