Camera
Image Sensor: 1/2.5" CMOS
Max. Resolution : 2560 (H) × 2560 (V)
RAM/ROM:1 GB / 4 GB
Scanning System:Progressive
Electronic Shutter Speed: Auto/Manual 1/3 s–1/100,000 s
Minimum Illumination:
0.005 lux@F1.6 (Color, 30 IRE)
0.0005 lux@F1.6 (B/W, 30 IRE)
0 lux (Illuminator on)
S/N Ratio:> 56 dB
Illumination Distance : Up to 15 m (49.21 ft) (IR)
Illuminator On/Off Control : Auto;Manual
Illuminator Number : 3 (IR LED)
Lens
Lens Type: Fixed-focal
Lens Mount :M12
Focal Length: 1.68 mm
Max. Aperture: F2.0
Field of View : H: 185°; V: 185°; D: 185°
Iris Contr: Fixed
Close Focus Distance: 0.3 m (0.98 ft)
Smart Event: IVS (Perimeter Protection) ,People Counting ,Heat Map .
Audio
Built-in MIC: Yes, built-in dual Mic
Built-in Speaker : Yes, built-in speaker
Audio Compression: PCM; G.711a; G.711Mu; G.726
Network
Network Port :RJ-45 (10/100 Base-T)
SDK and API :Yes
User/Host :20 (Total bandwidth: 80 M)
Storage: FTP; SFTP; Micro SD card (support max. 512 GB); NAS
Browser : IE: IE11; Chrome; Firefox
Management Software : Smart PSS Lite; DSS; DMSS; DoLynk Care
Mobile Client :iOS; Android
Electrical
Power Supply: 12 VDC, 1 A; PoE (802.3af)
Power Consumption:Basic power consumption: 3.4W (12V DC); 4.3W (PoE)
Basic: 1.4 W (12 VDC), 2.6 W (PoE); Max.: 8.1 W (12 VDC), 10.1 W (PoE) (ICR switch + IR intensity)
